Description
What makes the difference
- Optimized for compact sealed enclosures of 15-25L (0.52-0.88 cu.ft)
- Excels in bass reflex enclosures of 20-35L (0.71-1.23 cu.ft)
- Delivers high sound pressure levels for impactful bass response
Technical characteristics
- Diameter: 10″ (250mm)
- Voice-coil diameter: 2″ (50mm)
- Voice-coil height: 1″ (25mm)
- Magnet: 4¾” (120mm)
- Max. power: 400W
- Nom. power: 200W RMS
- Sensitivity (2.83 V/1 m): 85dB
- Frequency response: 36Hz – 500Hz
- Impedance: 4Ω
Specification
Nominal Power
250W RMS
Maximum Power
500 W
Sensitivity (2,83V/1m)
87.18dB
Cone
DFS® (Dual Fiberglass Structure)
Surround
Butyl
Nom. impedance
4 Ohms
DC Resistance
4 Ohms
VC diameter
50mm (2″)
VC height
25mm (1″)
Former
Kapton
Layers
4
Wire
Copper
Inductance
2.85mH
Xmax
± 8.5mm 0(5/16)“
Magnet d x h
120mm x 30mm (4(23/32)” x 1(3/16)“)
Magnet Weight
1250g (2.75lbs)
Flux Density
0.8T
Gap height
8mm 0(5/16)“
Net Weight
3.7kg (8.1lbs)
Fs
24.7 Hz
Vas
86.91 liters
Qts
0.691
Qes
0.764
Qms
5.49
Re
4.01 Ohms
Sd
510.71 cm2
Cas
6.19E-07 m5/N
Mas
67.1 kg/m4
Ras
1896.71 Ohms.ac
Cms
2.37E-04 m/N
Mms
175g
Rms
4.947Kg/s
Ces
1227.64mF
Les
33.82mH
Res
28.82 Ohms
BI
11.94N/A
SPL
84.18 dB/W/m
Load
Volume
Port Ø
Port Length
F-3(Hz)
Ported
20l-0.70cu.ft
9 cm-31/2“
35 cm-133/4“
38Hz
Ported
30l-1.05cu.ft
9 cm-31/2“
35 cm-133/4“
32Hz
Ported
35l-1.23cu.ft
9 cm-31/2“
35 cm-133/4“
31Hz
Sealed
15l-0.52cu.ft
–
–
38Hz
Sealed
20l-0.70cu.ft
–
–
35Hz
Sealed
25l-0.88cu.ft
–
–
35Hz
