Audison Forza AF M8.14 bit DSP Amplifier

Audison AF M8.14 bit DSP Amplifier | 1120W | 14-Channel DSP | 8 x 140W @ 2Ω | Class D Fully Bridgeable

Overview:
The Audison AF M8.14 bit is a compact yet powerful 14-channel DSP amplifier, delivering 1120W total output with 8 x 140W @ 2Ω (or 90W x 8 @ 4Ω) using next-gen Audison D-Class (ADT) technology. Built for high-fidelity car audio applications, it features native 24-bit/96kHz DSP processing, certified for Hi-Res Audio with bandwidth up to 40 kHz.

This amplifier offers unmatched flexibility, with bridgeable channel pairs delivering 280W x 4 @ 4Ω, six processed preamp outputs, and full compatibility with Audison B-CON for wireless hi-res streaming with Absolute Volume control. Designed for seamless OEM integration, it includes 8 analog inputs + optical Toslink and supports expansion cards (F4IN, F2O) for system scalability.

The advanced bit Drive software allows complete signal routing, de-EQ, de-Time, de-Phase, and real-time tuning with acoustic RTA integration—simplifying tuning and guaranteeing superior sound quality.

Key Features:

• Latest ADT (Audison D-Class) Technology: Delivers superior clarity and power efficiency (up to 82%)
• Hi-Res Audio Certified DSP: 24-bit/96kHz resolution, with response up to 40 kHz
• Bridgeable Design: 280W x 4 @ 4Ω via bridged channels
• 14 DSP-Controlled Outputs: 8 amplified + 6 pre-outs for extended configurations
• Advanced bit Drive Software: With real-time acoustic RTA and Final EQ tools
• Comprehensive OEM Integration:
  • 8 analog inputs + optical Toslink input
  • Optional F4IN (4 extra analog inputs) and F2O (Coaxial/second Toslink)
• Universal Speaker Simulator (USS): Ensures compatibility with any OEM head unit
• Built-in Electrical & Acoustic Analysis: For accurate system correction and integration
• iDatalink Maestro AR Support: Seamless interface with OEM infotainment systems
• Dual Power Supply Design: Maintains stable DSP operation during voltage drops
• B-CON Absolute Volume Support: Maintains full dynamic range during Bluetooth playback

Technologies:

• bit Drive Software Platform: Simplified tuning, configuration, and real-time analysis
• All Channels Driven Philosophy: Delivers consistent power across all outputs
• De-EQ, De-Time, De-Phase Capabilities: For full restoration of OEM audio signals
• Quick I/O Configuration: Speeds up system setup and customization
• Phase Matching and Delay Compensation: Maintains stereo image accuracy
• Final EQ Function: Fine-tunes frequency response while preserving left/right balance

Box Contents:

• USB Cable: For PC connection and DSP tuning
• Control Cable (AF bit): For memory switching and remote turn-on
• DSP Out Cable (6CH): Connects AF bit amplifier to additional Forza D amplifiers
• Speaker Out Cable (8CH): Pre-labeled speaker output wiring
• Pre-In Cable (8CH): RCA input harness for aftermarket sources
• Speaker-In Cable (8CH): High-level input harness for OEM integration
• Forza Install Kit: Includes all necessary components for secure installation

Compatible Accessories:

• DRC MP CAN: OLED remote controller with joystick, volume/mode control, and B-CON sync
• DRC AC: Compact remote for volume, subwoofer, source switching, and preset recall
• C2O: High-performance crossover for precision frequency management
• F2O: Digital input expansion (Coaxial or Toslink)
• F4IN: Analog input expansion (adds 4 SPK IN channels, 3.2–32 VRMS range)
• AF LINK Cable: Connects DSP OUT of AF bit amps to PRE IN of AF D series
• AFM – CLK: Cooling fan and bracket for optimal airflow in tight installations
• AFBMW ReAMP 3: Plug & Play T-Harness for BMW vehicles with RAM modules
