Focal Auditor AP 4340
Original price was: ₹17,499.00.₹13,124.25Current price is: ₹13,124.25.
Auditor AP 4340 4/3/2-Channel A/B Class Amplifier
Delivering a powerful blend of performance and versatility, the AP 4340 features RCA inputs, bridgeable channels, and stable 2Ω operation. With high/low-pass crossovers, bass boost, and full-range mode, it’s ideal for custom car audio setups. Housed in a heat-dissipating aluminum chassis, it ensures clear sound and long-lasting reliability.
Description
WHAT SETS IT APART
- Excellent power-to-quality ratio
- Bridgeable configuration
- Operates reliably at 2Ω load
TECHNICAL CHARACTERISTICS
- 4/3/2-channel A/B class amplifier
- RCA inputs
- CEA Power (4Ω): 4x70W RMS
- Max. power (2Ω): 4x95W
- Max. power (bridged 4Ω): 2x190W
- High-pass crossover (channel 1-2): 60Hz – 1.2KHz
- High-pass crossover (channel 3-4): 100Hz – 2.2KHz
- Low pass crossover: 50 – 250Hz
- Full range mode
- Bandwidth: 10Hz – 30KHz
- Dimensions (LxHxW): 1325/64“x2″x91/4” (340x50x235mm)
Auditor AP 4340 Amplifier
- RCA connectivity for aftermarket head units
- Built-in adjustable crossovers: High-pass / Low-pass & bass boost settings
- 4/3/2-channel Class A/B audio amplifier
- Durable aluminum chassis
- Designed for efficient heat dissipation
Specification
CEA power (4Ω)
4x70W RMS
Max. power (2Ω)
4x95W
Max. power (4Ω bridged)
2x190W
Bandwidth (-3dB)
10Hz – 30kHz
THD
0,06%
Channel separation
(1 KHz)
45 dB
SNR (1W/A)
76 dBA
Low level input sensitivity
160 mV
High-pass crossover
(channel 1-2)
60Hz to 1.2kHz
Low-pass crossover
(channel 3-4)
50 to 250Hz
Full-Range mode
Yes
Dimension (Lxlxh)
1325/64x131/32x91/43” (340x50x235mm)
Weight
2.75kg 6.06lbs
Protections
Short-circuit
Low impedance
DC
Polarity reversal
Thermal over / under voltage4x70W RMS
